TC50 Hot Runner Temperature Controllers
Features
- It can precisely control the temperature in the hot runner system, improve production efficiency, reduce production costs, and ensure stability and quality during the injection molding process.
- The 7" LCD display with touch panel can display real-time temperature and other control parameters, such as mold leakage detecting, synchronous heat up and cool down, mold memory, group setup function, power balance detection and display, self diagnosis log.
- It also supports injection machine connect for I/O function and optional VNC function, achieving intelligent one-stop production control.
- Thermocouple type: J/K
- Temperature unit: ℃/℉
- Heating mode selectable
- The maximum drive current is 15 ampere for each zone
- Temperature PID control
- Zero cross/Phase angle output trigger modes
- Auto detect the frequency of power source
- The current detect and display
- The output with auto/manual setting
- The soft-start for dehumidification
- Boost
- Standby
- Output mode: Stop/Manual/Slave/continually selectable when Thermo-coupler broken
- Overload protection for electric Overload protect for heating output
- The protect mode of power source when wrong input
- Auto shutdown when abnormal work on module
- The fast fuse used to protect TRIAC
