TC5V Valve Gate Module

  • TC5V Valve Gate Module


    • The TC5V Valve Controller supports various input signals, including AC220/110, DC24, and switch-type. Similarly, the output mode can also be selected as AC220/110, DC24, and switch-type.
    • The valve controller's time display function can be adjusted to the first decimal place and provides a time counting function that allows selecting either cumulative or countdown timing. It also offers the option of a pressure-maintaining mode to ensure valve stability.
    • The electronic switch is a standard configuration of the valve controller and can support up to 600mA of current, which can extend the lifespan. If a larger output current is required, a mechanical switch can be selected as an optional accessory.

+ Add to Inquiry
TC5V Model
Panel measurement 50*176mm
Display 7-Section tube 0.4*4*2
Power switch Manual dial type
Input power AC230 (50/60Hz)
Trigger voltage (Must jump JP), AC110 (50/60Hz), AC230 (50/60Hz), DC24, Switch (DC24)
Output power (must jump JP), AC110(RELAY/electronic switch 4VA), AC230 (RELAY,2A/electronic switch 600mA),DC24 (RELAY/electronic switch 4W), RELAY-2A/electronic switch-600mA (either one)
Keys 5 keys (select/confirm, manual output, plus, minus, time setting)
Function display lamps A/B mode lamp, OPEN lamp, SIGNAL lamp, pressure retaining lamp, manual output lamp
